This part of the tutorial will present the steps for weaving a 2 color arrowhead pattern wherer the colors alternate sides.
The headstick configuration has one half the warp strands that form the arrowhead as one collor and the other half a second color. Weaving will start on the right side of the work-piece. The weft strands from the two sides meet at the middle where they become the middle warp strands. [NOTE] There are two formes of the two colored arrowhead:
In the other form the colors of the arrowheads stay on the same side. |
||
| Previous | Next |
Headstick configuration for 2 color arrrowhead,
|
|
| Top of Page | Next |
|
Select the row 1 right side weft strand.
|
|
| Previous | Next |
|
Pass the weft strand through the open shed to the middle of the warp strands that will become the arrowhead design. |
|
| Previous | Next |
|
Form the interlock in the right hand side of row 1 weft strand.
Place the weft strand in the top layer of the shed. |
|
| Previous | Next |
|
Reverse the shed on the right hand side of row 1.
Work from the righ hand edge to the middle of the shed. |
|
| Previous | Next |
|
Secure the row 1 right side weft strand interlock. |
|
| Previous | Next |
|
Select the left side row 1 weft strand.
The first warp strand on the left hand side is selected as the row 1 left side weft strand. |
|
| Previous | Next |
|
Pass the left side row 1 weft strand throught the open shed to the middle of the shed. |
|
| Previous | Next |
|
Form the interlock in the left hand side of row 1 weft strand.
Secure the interlock. |
|
| Previous | Next |
|
Reverse the left hand side of row 1 the shed.
Work from the left hand edge to the middle of the shed. |
|
| Previous | Next |
|
Secure the row 1 middle strands.
Then place the right weft strand in the bottom layer of the shed. Place the left weft strand in the top layer of the shed. Check to see that the over/under configuration is maintained. |
|
| Previous | Next |
|
Set the row 1 weave.
Check individual strands to see that they are snug and even. [TIP] Use index finger as a beater. |
|
| Previous | Next |
|
Select the row 2 right side weft strand.
|
|
| Previous | Next |
|
Pass the row 2 weft strand through the open shed to the row 1 right side weft strand interlock. |
|
| Previous | Next |
|
Form row 2 right side weft strand interlock.
When the row 2 right side interlock is formed the row 2 right side weft strand become a top layer warp strand and the warp strand becomes the next part of the row 2 right side weft strand. |
|
| Previous | Next |
|
Pass the row 2 weft strand to the middle.
The row 2 weft strand becomes the left middle warp strand when it is placed in the top layer of the shed. |
|
| Previous | Next |
|
Secure the left middle warp strand by placing the right middle warp strand in the bottom layer of the shed. Check to see if the over/under configuration is maintained. |
|
| Previous | Next |
|
Reverse the row 2 right hand side of the shed.
Work from the righ hand edge to the middle of the shed. The right hand row 2 weft strand becomes the left side middle warp strand. |
|
| Previous | Next |
|
Secure the middle warp strands |
|
| Previous | Next |
|
Select the left side row 2 weft strand.
|
|
| Previous | Next |
|
Pass the row 2 left side weft strand through the open shed to the row 1 left side interlock. |
|
| Previous | Next |
|
Form the interlock in the left hand side row 2 weft strand.
When the row 2 left side interlock is formed the weft strand becomes a warp strand. The warp strand that was next to the row 1 interlock becomes the next part of the row 2 left side weft strand. |
|
| Previous | Next |
|
Pass the row 2 left weft strand through the shed to the middle of the work-piece. |
|
| Previous | Next |
|
Then secure the row 2 middle strands. |
|
| Previous | Next |
|
Reverse shed on the left hand side of row 2 .
Work from the left hand edge to the middle of the shed |
|
| Previous | Next |
|
Set the row 2 weave.
Check individual strands to see that they are snug and even. [TIP] Use index finger as a beater. |
|
| Previous | Next |
|
Weave the right side of row 3.
|
|
| Previous | Next |
|
Weave the left side of row 3.
|
|
| Previous | Next |
|
Weave row 4. The same sequesence of weaving steps are requires as used for row 3. |
|
| Previous | Next |
|
Weave row 5. The same sequesence of weaving steps are requires as used for row 4. |
|
| Previous | Next |
|
Row 6 requires the same sequesence of weaving steps as row 5. This completes the first segment of the arrowhead pattern. [OBSERVE] Each segment is composed of two parts of the arrowhead.
|
|
| Previous | Next |
|
Segment 2 of arrowhed pattern.
[NOTE] To produce a complete arrowhead designe, two segments of the basic patter are required. Continue adding segments untill the work-piece is the desired length |
|
