Diamond checker board axcent for joining color bands.
  • This part of the tutorial uses two sets of yarn strands that have different colors and an even number of strands.
  • The top layer of the shed is on the left to right diagonal.
  • The first strand on the right hand side is in the top layer of the shed.
  • The checker board pattern is used to turn the strand back into their original side.

Start Tutorial

This tutorial will illistrate the weaving of adiamond accent used to join two color bands.

The first checker board diamond is shown. 		[figure-1] color-bands-part-1-row1-1

Go to: Top of page Next

row 1
Weave the first row of the diamond checker board pattern by following the steps for weaving a row of diagonally interlaced fingerweaving.

[OBSERVE] In the center of the row, there are two right hand color band strands corssing two left hand color band strands. 		[figure-2] [click here to see video]

Previous Next

row 2

Weave the second row of the diamond checker board pattern by following the steps for weaving a row of diagonally interlaced fingerweaving.

[OBSERVE] In the center of the row, there are four right hand color band strands corssing four left hand color band strands. 		[figure-3] [click here to see video]

Previous Next

row 3

Weave the third row of the diamond checker board pattern by following the steps for weaving a row of diagonally interlaced fingerweaving.

[OBSERVE] In the center of the row, there are six right hand color band strands corssing six left hand color band strands. 		[figure-4] [click here to see video]

Previous Next

row 4

Weave row 4 untill the next top shed strand is in the top layer of the left hand side color band.

[OMSERVE] the next two bottom layer strands are in the right hand color band. 		[figure-5] [click here to see video]

Previous Next

row 4

Start first interlock.

Step 1--- first interlock
  • Use the right hand thumb and index finger to reach under the first bottom shed layer strand.
  • Then over the second bottom layer shed strand.
  • Pull the third bottom layer strand to the right.
[figure-6] [click here to see video]

Previous Next

row 4

Step 2--- first interlock
  • Thransfer the first and third bottom shed strands to the index finger of the right hand.
[NOTE] Check the over/under configuration of the transfered strands. 		[figure-7] [click here to see video]

Previous Next

row 4

Step 3--- first interlock
  • Use the thumb and index finger to pick up the next two strands.
  • Place the picked up strands under the index finger of the left hand.
[NOTE] This completes the first interlock.

[NOTE] There are a total of six interlocks in this row. 		[figure-8] [click here to see video]

Previous Next

row 4

Start second interlock.

Step 1--- second interlock
  • Use the right hand thumb and index finger to reach under the first bottom shed layer strand.
  • Then over the second bottom layer shed strand.
  • Pull the third bottom layer strand to the right.
[figure-9] [click here to see video]

Previous Next

row 4

Step 2--- second interlock
  • Thransfer the first and third bottom shed strands to the index finger of the right hand.
[NOTE] Check the over/under configuration of the transfered strands. 		[figure-10] [click here to see video]

Previous Next

row 4

Step 3--- second interlock
  • Use the thumb and index finger to pick up the next two strands.
  • Place the picked up strands under the index finger of the left hand.
[NOTE] This completes the second interlock. 		[figure-11] [click here to see video]

Previous Next

row 4

Start third interlock.

Step 1--- third interlock
  • Use the right hand thumb and index finger to reach under the first bottom shed layer strand.
  • Then over the second bottom layer shed strand.
  • Pull the third bottom layer strand to the right.
[figure-12] [click here to see video]

Previous Next

row 4

Step 2--- third interlock
  • Thransfer the first and third bottom shed strands to the index finger of the right hand.
[NOTE] Check the over/under configuration of the transfered strands. 		[figure-13] [click here to see video]

Previous Next

row 4

Step 3--- third interlock
  • Use the thumb and index finger to pick up the next two strands.
  • Place the picked up strands under the index finger of the left hand.
[NOTE] This completes the third interlock. 		[figure-14] [click here to see video]

Previous Next

row 4

Start fourth interlock.

Step 1--- fourth interlock
  • Use the right hand thumb and index finger to reach under the first bottom shed layer strand.
  • Then over the second bottom layer shed strand.
  • Pull the third bottom layer strand to the right.
[figure-15] [click here to see video]

Previous Next

row 4

Step 2--- fourth interlock
  • Thransfer the first and third bottom shed strands to the index finger of the right hand.
[NOTE] Check the over/under configuration of the transfered strands. 		[figure-16] [click here to see video]

Previous Next

row 4

Start fourth interlock.

Step 1--- fourth interlock
  • Use the right hand thumb and index finger to reach under the first bottom shed layer strand.
  • Then over the second bottom layer shed strand.
  • Pull the third bottom layer strand to the right.
[figure-15] [click here to see video]

Previous Next

row 4

Step 2--- fourth interlock
  • Thransfer the first and third bottom shed strands to the index finger of the right hand.
[NOTE] Check the over/under configuration of the transfered strands. 		[figure-16] [click here to see video]

Previous Next

row 4

Step 3--- fourth interlock
  • Use the thumb and index finger to pick up the next two strands.
  • Place the picked up strands under the index finger of the left hand.
[NOTE] This completes the fourth interlock. 		[figure-17] [click here to see video]

Previous Next

row 4

Start fifth interlock.

Step 1--- fifth interlock
  • Use the right hand thumb and index finger to reach under the first bottom shed layer strand.
  • Then over the second bottom layer shed strand.
  • Pull the third bottom layer strand to the right.
[figure-18] [click here to see video]

Previous Next

row 4

Step 2--- fifth interlock
  • Thransfer the first and third bottom shed strands to the index finger of the right hand.
[NOTE] Check the over/under configuration of the transfered strands. 		[figure-19] [click here to see video]

Previous Next

row 4

Step 3--- fifth interlock
  • Use the thumb and index finger to pick up the next two strands.
  • Place the picked up strands under the index finger of the left hand.
[NOTE] This completes the fifth interlock. 		[figure-20] [click here to see video]

Previous Next

row 4

Start stixth interlock.

Step 1--- sixth interlock
  • Use the right hand thumb and index finger to reach under the first bottom shed layer strand.
  • Then over the second bottom layer shed strand.
  • Pull the third bottom layer strand to the right.
[figure-21] [click here to see video]

Previous Next

row 4

Step 2--- sixth interlock
  • Thransfer the first and third bottom shed strands to the index finger of the right hand.
[NOTE] Check the over/under configuration of the transfered strands. 		[figure-22] [click here to see video]

Previous Next

row 4

Step 3--- sixth interlock
  • Use the thumb and index finger to pick up the next two strands.
  • Place the picked up strands under the index finger of the left hand.
[NOTE] This completes the sixth interlock. 		[figure-23] [click here to see video]

Previous Next

Finish the weaving of row4 [figure-24] [click here to see video]

Previous Next

Weave row 5 [figure-25] [click here to see video]

Previous Next

Weave row 6

[NOTE] Add aditional rows of weaving until the work piece is the desired length. 		[figure-26 ] [click here to see video]
